Technical parameters:

1, the minimum aperture of 0.35 mm.

2、Max AR 16:1

3. The minimum hole copper thickness is 100um

4. The minimum line width and line spacing is 4mil/3mil.

design feature

1. 12L HLC, with a thickness of 2.6mm

2. Material M6G+RF30

3, POFV hole 0.45 mm.

4, the hole wall copper thickness min 75um.

5. Outer layer LW/S 5/5mil

application area

Aerospace military industry, communication base station, medical treatment, etc.
